Alpha Alaflex Style 2213 EAM is a four ply laminate made with a fiberglass scrim adhered with a flame retardant adhesive to an aluminum foil face and heat-sealable film backing both sides. 1) Films – Endalon; 0.8 mil, Polyester; 0.6 mil. 2) Base Fabric – Fiberglass 2 x 2 scrim 3) Adhesive – Flame retardant ; Thermo setting 4) Foil – Aluminum ADVANTAGES Heat – sealable, Excellent vapor barrier, Solvent – sealable APPLICATIONS Flex Duct liner, Insulation Board Facing
Lower Continuous Operating Temperature (°F): 0
Upper Continuous Operating Temperature (°F): 265
| Width | 60" |
|---|---|
| Roll Length | 2500 |
| Color | Foil/Scrim/PET |
| Base Fabric | 2×2 Glass Scrim |
| Coating Type | NA |
| Thickness (in.) ASTM-D-1777 | 0.006 |
| Weight (oz/sy) ASTM-D-3776 | 2.7 |
| Lower Service Temperature Limit (°F) | 0 |
| Upper Service Temperature Limit, Continuous (°F) | 265 |
| Tensile Strength ASTM-D-5035 | 25 |
| Tear Strength ASTM-D-1424 | 450 |
| Tear Strength ASTM-D-5587 | NA |
| Burst Strength ASTM-D-3786 | NA |
| Flame Resistance - Afterglow (sec) ASTM D-6413 | 0.5 |
| Flame Resistance - Flameout (sec) ASTM D-6413 | 0 |
| Flame Resistance - Char Length (in.) ASTM D-6413 | 4.5 |
| UV Resistance ASTM-G-154 | NA |
